RWB2246 Split Anchor Bollard without Pin | Marine Anchoring Solutions

🔧 Product Description

RWB 316 Stainless Steel Split Anchor Bollard without Pin - Part Number: RWB2246

A compact cast 316 stainless-steel split bollard for securing 8-10mm anchor chain on the foredeck. This version is supplied without the removable pin and is suited to installations where an existing compatible pin is retained or a pin is not required by the chosen chain-securing method.

⚙️ Key Features

• Cast 316 stainless-steel construction
• Split-post form accepts chain directly
• Polished marine finish
• Compact foredeck footprint
• Four countersunk mounting holes

📏 Specifications

• Recommended chain size: 8-10mm
• Overall height: Approximately 84mm
• Base dimensions: Approximately 60 × 60mm
• Mounting holes: Four, for approximately 6mm countersunk fasteners
• Pin: Not included

🔄 Cross Reference & Comparable Options

• Pinned version: RWB2247
• Comparable split anchor bollard: 402201

🛠️ Installation & Use

• Through-bolt to a reinforced deck with a substantial backing plate
• Use only where the chain can be retained securely without the missing pin
• Confirm chain diameter and link width fit the split post
• Do not rely on the windlass alone to secure the anchor at sea
• Inspect the bollard and deck structure after heavy shock loading

📦 Condition

• Brand new
• Supplied as one split anchor bollard without pin
• Supplied in original or equivalent packaging
