T70628 Cyclone 3ft Open Array

CYCLONE RADAR

55 Watt open array with CHIRP Pulse Compression technology. Available with your choice of a 3, 4, or 6-foot antenna array. 55 watt solid-state radar is equivalent to a 6 kW magnetron radar, with range performance up to 72 NM.

EVOLVED FOR THE OCEAN

With a 55-watt solid-state transmitter, Cyclone delivers excellent target separation and long-range resolution using CHIRP pulse compression and beam sharpening technology. The power output of Cyclone is equivalent to a 6kW magnetron radar and gives Cyclone a range of up to 72 nautical miles.

Cyclone radars feature innovative detection capabilities, including Doppler target tracking, RangeFusion™ technology, Bird Mode, and high-speed 60 rpm imaging.

Aircraft wing inspired

Engineered for extremes with best-in-class 100-knot wind rating and designed to meet the commercial grade IEC 62388 standard for ship-borne radar.

Low profile

At 13.1 inches (335 mm) tall, Cyclone's lower profile allows greater flexibility of boat architecture and more adaptable installation options.

Clean installation

Innovative pedestal design conceals cable connections for a cleaner installation. Built in cable gland to allow sleeker design configuration to boat designers.

RangeFusion™ technology

Available exclusively on Cyclone radars, RangeFusion™ technology combines short and long pulses into the single high clarity radar image, delivering exceptional short-range and long-range targets simultaneously.

Doppler target tracking

Available exclusively on Quantum 2 radomes and Cyclone open array radars, Doppler allows the radar to instantly detect targets in motion and display them in a unique colour palette. Inbound targets are red while outbound targets are green for improved awareness in high-traffic situations.
