🔧 Product Description

Aftermarket replacement Inline Fuel Filter Assembly - Part Number: 3AC-02230-0

New aftermarket inline fuel-filter assembly replacing Tohatsu 3AC-02230-0 for carburetted two-stroke outboards.

⚙️ Key Features

• Complete inline fuel-filter assembly for the listed Tohatsu engine family

• Moulded marine-grade housing with integrated hose connections

• Direct replacement dimensions for the specified fuel-system location

• Protects carburettors and fuel pumps from solid contamination

• Engine model and hose size must be confirmed before installation

🧰 Kit / Assembly Contents

• 1 × Complete inline fuel-filter assembly - Tohatsu P/N 3AC-02230-0

• 1 × Moulded filter housing with integrated hose connections

• 1 × Installed replaceable/filtering element - serviced as a complete assembly

🔄 Supersession & Cross Reference

OEM Supersession Chain:

• 3AC-02230-0 / 3AC022300 (Tohatsu OEM reference)

OEM / Related Numbers:

• 3AC022300

• 3AC-02230-0M

Aftermarket / Verified Equivalents:

• Recmar: REC3AC-02230-0

• Aftermarket Tohatsu 3AC fuel-filter assembly

🚤 Compatibility

Commonly used on:

• Tohatsu outboard fuel systems

Typically suits:

• Engine models:

• M25C2 and M25C3

• M30A4

• M40D and M40D2

• M50C, M50D and M50D2

• M60A, M60B and M60C

• M70A2, M70B and M70C

• Additional Tohatsu two-stroke 25HP-140HP applications where 3AC-02230-0 is specified

• HP Range: 25HP - 140HP

• Year Range: Model- and serial-dependent two-stroke production

• Model / Serial Identification: Confirm hose diameter and filter orientation. Some later models use fuel filter 3B7-02234-0.

🔌 Function

The inline fuel-filter assembly traps rust, scale and other debris before fuel reaches the carburettors or fuel-pump system. Clean fuel flow protects jets, needle valves and internal pump components from restriction and contamination.

Common signs of failure:

• Engine hesitates or loses power as throttle is increased

• Fuel flow appears restricted or the primer bulb collapses

• Debris or water is visible inside the filter body

• Filter housing, hose tails or seals are cracked or leaking

• The scheduled fuel-system service interval is due

📦 Condition

• New aftermarket replacement part

• Brand new

• Supplied in original or equivalent packaging
