TOOLTRIM1 Aftermarket Marine Trim Piston Tool 38mm | Sawley's Select Marine Parts

🔧 Product Description

Four-pin trim/tilt cylinder end-cap tool with a nominal 38mm working diameter. Recmar TOOLTRIM1 is primarily used on selected Yamaha outboards and operates with a 1/2-inch drive and the appropriate replaceable pin set.

The dedicated circular spanner applies load evenly across the cap holes and is substantially safer than striking the gland with a punch.

⚙️ Key Features

• Nominal 38mm four-pin pattern

• 1/2-inch square-drive operation

• Replaceable pins suit differing end-cap hole sizes

• Designed for trim-cylinder seal and piston service

📋 Kit Contents

• 1 × 38mm four-pin tool body - TOOLTRIM1 / RECTOOLTRIM1

• RECPIN4 and RECPIN4.5 pins not included unless stated

• Drive handle not included

🔄 Supersession & Cross Reference

• Recmar references: TOOLTRIM1 / RECTOOLTRIM1

• Related pin sets: RECPIN4 and RECPIN4.5

• Included as the 38mm tool in TOOLTRIMKIT

• No single OEM tool number was verified across every application

🚤 Compatibility

• Selected Yamaha F25-F40 outboards

• Selected Yamaha F150 models from approximately 2011 onward

• Selected Yamaha F200-F250 3.3L and F225-F300 4.2L engines

• Selected Yamaha 225HP two-strokes

• Confirm 38mm cap diameter, four-pin pattern and pin size

🔌 Function

Engages the trim-cylinder gland/end cap for controlled removal and installation during rod, piston, O-ring and seal service. The trim unit should be securely held and depressurised before dismantling.

📦 Condition

• Brand-new aftermarket Recmar tool

• One 38mm tool body supplied

• Pins and 1/2-inch drive equipment may be sold separately
